Device:A-0702A-1A
Rating: 1A
* Will hold 100% of rating
current indefinitley at 25 Deg.
Will trip within 1 hour at 175%
of load at 25 Deg.
Max. Voltage. 125/250VAC
Hole Size:9.0mm
Manufacturer:Sang Mao
Stock No: 47982
Part No: A-0702A-4A
Description: 4A 250VAC Panel Circuit Breaker
Qty on Hand: 32
Pricing
Device:A-0702A-4A
Rating: 4A
* Will hold 100% of rating
current indefinitley at 25 Deg.
Will trip within 1 hour at 175%
of load at 25 Deg.
Max. Voltage. 125/250VAC
Hole Size:9.0mm
Manufacturer:Sang Mao
Stock No: 17781
Part No: --
Description: 3Amp 250VAC Flush Mt Circuit Breaker
Qty on Hand: 4
Pricing
Value: 3A
Spec. At 25 Deg.C
Hold Current. 100% load indefinitly.
Trip Current. With one hour at
135% load. With one min at
200% load.
Max Voltage. 250VAC~32VDC
Dim. 52(L)x13.5(H)x15.5(W)mm
Stock No: 17776
Part No: --
Description: A0701 3A 250VAC Circuit Breaker (4Pcs)
Qty on Hand: 17
Pricing
* Rated: 3A 250VAC
* Desc. Will hold 100% of rating
* Will trip within 1 hour at 125%
of load at 25 Deg.
* Max. Voltage. 250VAC~50VDC
* Dims. 36(H)x31(L)x15(W)
* Pannel Cutout. 12mm
* ROC#17776
* You Receive 4 Breakers.
Stock No: 37671
Part No: ZE-800
Description: 3A Resettable Thermal Cct. Breaker
Qty on Hand: 68
Pricing
Value: 5A
Spec. At 25 Deg.C
Hold Current. 100% load indefinitly.
Trip Current. With one hour at
135% load. With one min at
200% load.
Max Voltage. 250VAC~32VDC
Dim. 52(L)x13.5(H)x15.5(W)mm
Stock No: 40246
Part No: SB8
Description: 5A Resettable Thermal Circuit Breaker
Qty on Hand: 21
Pricing
Device:A-0710W
Value: 5A
* At 25 Deg.C
Hold Current. 100% load indefinitly.
Trip Current. With one hour at
135% load. With one min at
200% load.
Max Voltage. 250VAC~32VDC
Size(LHWmm): 51.6x18.6x18.6
Manufacturer:Sang Mao
Stock No: 17777
Part No: --
Description: 5A 250VAC Circuit Breaker
Qty on Hand: 38
Pricing
Value: 5A
Desc. Will hold 100% of rating
current indefinitley at 25 Deg.
Will trip within 1 hour at 125%
of load at 25 Deg.
Max. Voltage. 250VAC~50VDC
Dimensions. 36(H)x31(L)x15(W)
Panel Cutout. 12mm
Volts. 250VAC
Stock No: 46559
Part No: ZE-800
Description: 6A Resettable Thermal Cct. Breaker
Qty on Hand: 262
Pricing
Value: 10A
* Will hold 100% of rating
current indefinitley at 25 Deg.
Will trip within 1 hour at 125%
of load at 25 Deg.
Max. Voltage. 250VAC~50VDC
Dimensions. 36(H)x31(L)x15(W)
Pannel Cutout. 12mm
Volts. 250VAC
Stock No: 17784
Part No: --
Description: 10Amp 250VAC Flush Mt C/Breaker
Qty: Contact For Availability(Lead Time)
Pricing
Value: 10A
Spec. At 25 Deg.C
Hold Current. 100% load indefinitly.
Trip Current. With one hour at
135% load. With one min at
200% load.
Max Voltage. 250VAC~32VDC
Dim. 52(L)x13.5(H)x15.5(W)mm
Stock No: 30637
Part No: A-0702
Description: 10A 250VAC Circuit Breaker
Qty on Hand: 31
Pricing
Value: 10A
* Will hold 100% of rating
current indefinitley at 25 Deg.
Will trip within 1 hour at 175%
of load at 25 Deg.
Max. Voltage. 125/250VAC
Pannel Cutout. 12mm
Stock No: 37674
Part No: W28-XQ1A-10
Description: 10A Resettable Thermal Circuit Breaker
Qty on Hand: 15
Pricing
Value: 20A
* Will hold 100% of rating
current indefinitley at 25 Deg.
Will trip within 1 hour at 125%
of load at 25 Deg.
Max. Voltage. 250VAC~50VDC
Dimensions. 36(H)x31(L)x15(W)
Pannel Cutout. 12mm
Volts. 250VAC
Stock No: 34904
Part No: IEGS1-29239-7-V
Description: 25A 80VDC Circuit Breaker
Qty: Contact For Availability(Lead Time)
Pricing
* Rated: 25A 250VAC
* Desc. Will hold 100% of rating
* Will trip within 1 hour at 125%
of load at 25 Deg.
* Max. Voltage. 250VAC~50VDC
* Dims. 36(H)x31(L)x15(W)
* Pannel Cutout. 12mm
* ROC#17778
* You Receive 4 Breakers.
Stock No: 16149
Part No: --
Description: 15Amp 250VAC Flush Mt Circuit Breaker
Qty on Hand: 4
Pricing
Value: 15A
* At 25 Deg.C
Hold Current. 100% load indefinitly.
Trip Current. With one hour at
135% load. With one min at
200% load.
Max Voltage. 250VAC~32VDC
Size(LHWmm): 52x13.5x15.5
Stock No: 45874
Part No: Ex9BH 1P C Curve 25A
Description: 25A 230/400~ 1P C Curve Circuit Breaker
Qty on Hand: 14
Pricing
Value: 30A
* Will hold 100% of rating
current indefinitley at 25 Deg.
Will trip within 1 hour at 125%
of load at 25 Deg.
Max. Voltage. 250VAC~50VDC
Dimensions. 36(H)x31(L)x15(W)
Pannel Cutout. 12mm
Volts. 250VAC
Stock No: 42693
Part No: NH2-100-32A
Description: 2 Pole 32A 400VAC Circuit Breaker
Qty on Hand: 2
Pricing
Device: A0701
Value: 35A
Desc. Will hold 100% of rating
current indefinitley at 25 Deg.
Will trip within 1 hour at 125%
of load at 25 Deg.
Max. Voltage. 250VAC~50VDC
Dimensions. 36(H)x31(L)x15(W)
Panel Cutout. 12mm
Volts. 250VAC
Stock No: 44782
Part No: Ex9BH 3P D Curve 50A
Description: 50A 400 VAC 3P D Curve Breaker(Box of 4)
Qty on Hand: 2
Pricing
